Large Fragment Plating System

Distal Humerus Bone Plate

Indications:

Supracondylar and intercondylar fractures of distal humerus
Comminuted fractures of distal humerus
Intra-articular and extra-articular fractures of distal humerus

Specifications

Features

Unique two column fixation with a single plate
Precontoured shape of the plate makes it side specific to be used separately for right and left humerus
Oblong hole for accurate placement of plate on bone
Head holes are suitable for 4.0 mm cancellous screws and shaft holes accept 3.5 mm cortex screws
Available in both Titanium and Stainless Steel

Profile:

Thickness (T): 2 mm
Hole Spacing (HS): 17 mm

No. of Holes	CODE - Left		CODE - Right
No. of Holes	S.S.	Titanium	S.S.	Titanium
2	653.02L	653.02TL	653.02R	653.02TR
3	653.03L	653.03TL	653.03R	653.03TR
4	653.04L	653.04TL	653.04R	653.04TR
5	653.05L	653.05TL	653.05R	653.05TR
6	653.06L	653.06TL	653.06R	653.06TR
