Large Fragment Plating System

Distal Femur Bone Plate

Indications:

Intra articular fractures of the distal femur both in coronal and saggital plane
Extra articular fractures of the distal femur
Fracture distal one third femur with extension into supracondylar or intercondylar region
Non-union and malunion of distal femur fractures

Specifications

Features

Low profile plate
Anatomically contoured
Allows dynamic compression of fracture fragment
Side specific, available separately for left and right leg
Head holes suitable for 6.5 mm cancellous screws and shaft holes accommodate 4.5 mm cortex screws
Available in both Titanium and Stainless Steel

Profile

Thickness (T): 4.5 mm
Width (W): 16 mm

No. of Holes	CODE -For Left Leg		CODE -For Right Leg
No. of Holes	S.S.	Titanium	S.S.	Titanium
5	808.05L	808.05TL	808.05R	808.05TR
6	808.06L	808.06TL	808.06R	808.06TR
7	808.07L	808.07TL	808.07R	808.07TR
8	808.08L	808.08TL	808.08R	808.08TR
9	808.09L	808.09TL	808.09R	808.09TR
10	808.10L	808.10TL	808.10R	808.10TR
11	808.11L	808.11TL	808.11R	808.11TR
12	808.12L	808.12TL	808.12R	808.12TR
13	808.13L	808.13TL	808.13R	808.13TR
