Large Fragment Plating System

Distal Tibia Bone Plate

Indications:

Distal third tibia fractures
Tibial pilon fractures
Nonunions and malunion of distal one third tibia & tibial pilon fractures

Specifications

Features

Low profile plate
Precontoured for fixation on anteromedial surface of distal tibia
Side specific design - available in left and right
Oblong hole for optimal placement of plate onto bone
Head holes suitable for 6.5 mm cancellous screws and shaft holes suitable for 4.5 mm cortex screws
Available in both Titanium and Stainless Steel

Profile

Thickness (T): 3.5 mm
Width (W): 16 mm
Hole Spacing (HS): 18 mm

No. of Holes	CODE - Left		CODE - Right
No. of Holes	S.S.	Titanium	S.S.	Titanium
5	652.05L	652.05TL	652.05R	652.05TR
6	652.06L	652.06TL	652.06R	652.06TR
7	652.07L	652.07TL	652.07R	652.07TR
8	652.08L	652.08TL	652.08R	652.08TR
9	652.09L	652.09TL	652.09R	652.09TR
10	652.10L	652.10TL	652.10R	652.10TR
11	652.11L	652.11TL	652.11R	652.11TR
12	652.12L	652.12TL	652.12R	652.12TR
13	652.13L	652.13TL	652.13R	652.13TR
14	652.14L	652.14TL	652.14R	652.14TR
15	652.15L	652.15TL	652.15R	652.15TR
