Large Fragment Plating System

fixLOCK Proximal Tibia Plate , 4.5 mm

Indications:

Split-type fractures of the lateral tibial plateau
Lateral split fractures with associated depressions
Pure central depression fractures
Split or depression fractures of the medial plateau
Bicondylar fractures
Mal-unions and non unions of the proximal tibia and tibial shaft

Specifications

Anatomically shaped- right or left configured
Fixed angle construct with convergence of proximal screws and the obliquely directed screws
Beveled tip for submuscular insertion with minimal soft tissue stripping
Smaller area of post-fixation avascularity
The combination of conventional and locking screws offers optimum fixation regardless of bone density
Screw heads are recessed into the plate holes for minimum screw prominence
Available in both Titanium & Stainless steel

No. of Holes	Stainless Steel		Titanium
No. of Holes	Code- Left	Code- Right	Code- Left	Code- Right
4	840.04L	840.04R	840.04TL	840.04TR
6	840.06L	840.06R	840.06TL	840.06TR
8	840.08L	840.08R	840.08TL	840.08TR
10	840.10L	840.10R	840.10TL	840.10TR
12	840.12L	840.12R	840.12TL	840.12TR
14	840.14L	840.14R	840.14TL	840.14TR
