Features
- Can be applied in various modes - compression, buttress and bridging mode
- Used as neutralisation and tension band plate on tibia
- Dynamic compression holes allow compression of fracture fragments
- Has a middle section which is placed at the centre of the fracture
- Fixation with 4.5 mm cortex screws and 6.5 mm cancellous screws
- Available in both Titanium and Stainless Steel
Profile (for S.S.)
- Thickness (T): 4 mm
- Width (W): 12 mm
- Hole Spacing (HS): 16 mm
- Center Hole Spacing (CHS): 25 mm
|
No. of Holes
|
CODE
|
|
S.S.
|
Titanium
|
|
2 |
618.02
|
618.02T
|
|
3
|
618.03
|
618.03T
|
|
4
|
618.04
|
618.04T
|
|
5
|
618.05
|
618.05T
|
|
6
|
618.06
|
618.06T
|
|
7
|
618.07
|
618.07T
|
|
8
|
618.08
|
618.08T
|
|
9
|
618.09
|
618.09T
|
|
10
|
618.10
|
618.10T
|
|
11
|
618.11
|
618.11T
|
|
12
|
618.12
|
618.12T
|
|
13
|
618.13
|
618.13T
|
|
14
|
618.14
|
618.14T
|
* Fixation With 4.5 and 6.5mm Screw. All Holes are designed as selfcompressing holes.
* All the ends are designed for cancelllous bone screw.
* Indication: As a tension neutralisation and tension band plate on the tibia (not intended for the femur). Plates with 2, 3, and 4 holes used in exceptional cases.
