Large Fragment Plating System

fixLOCK Femoral Head Locking Plate (Distal Femoral)

Indications:

Intercondylar fracture femur
Supracondylar fracture femur
Intercondylar fracture with ipsilaeral shaft fracture
Subtrochanteric femoral fracture- Plate of contralateral side, placed in reverse position

Specifications
Product Video

Anatomically right or left considering curvature of distal femur
Beveled tip for submuscular insertion with minimal soft tissue stripping
Smaller area of post-fixation avascularity
Screw trajectory designed for optimal fixation of comminuted fractures
The combination of conventional and locking screws offers optimum fixation regardless of bone density
Smooth transition from thin proximal segment and thick shaft segment makes the plate auto-contourable
Available in both Titanium & Stainless steel

No. of Holes	Stainless Steel		Titanium
No. of Holes	Code- Left	Code- Right	Code- Left	Code- Right
5	851.05L	851.05R	851.05TL	851.05TR
6	851.06L	851.06R	851.06TL	851.06TR
7	851.07L	851.07R	851.07TL	851.07TR
8	851.08L	851.08R	851.08TL	851.08TR
9	851.09L	851.09R	851.09TL	851.09TR
10	851.10L	851.10R	851.10TL	851.10TR
11	851.11L	851.11R	851.11TL	851.11TR
12	851.12L	851.12R	851.12TL	851.12TR
13	851.13L	851.13R	851.13TL	851.13TR
14	851.14L	851.14R	851.14TL	851.14TR
15	851.15L	851.15R	851.15TL	851.15TR
16	851.16L	851.16R	851.16TL	851.16TR
