Small Fragment Plating System

fixLOCK Olecranon Plate, 3.5 mm

Indications:

Complex extra and intra-articular olecranon fractures
Simple olecranon fractures
Pseudoarthrosis of the proximal ulna
Repair of olecranon after distal humerus surgery

Specifications

Anatomically pre-contoured, right and left configured
Used over the tensile surface of bones to work on tension band principle
Uniform stiffness of all segments, prolonging fatigue life of the implant
Smaller area of post-fixation avascularity
The combination of conventional and locking screws offers optimum fixation regardless of bone density
Pre-determined position and angle of the screws are adapted to allow reduction of fractures
Smooth transition from thin proximal segment to thicker shaft segment of the plate
Metaphyseal segment has 8 holes for 3.5 mm locking screws or 2.7 mm cortical screws including 1 hole in the tab
Available in both Titanium & Stainless steel

No. of Holes	Stainless Steel		Titanium
No. of Holes	Code- Left	Code- Right	Code- Left	Code- Right
6	903.06L	903.06R	903.06TL	903.06TR
7	903.07L	903.07R	903.07TL	903.07TR
8	903.08L	903.08R	903.08TL	903.08TR
9	903.09L	903.09R	903.09TL	903.09TR
10	903.10L	903.10R	903.10TL	903.10TR
