Features
- Designed in the shape of a half tube
- Used in areas where they are subjected to tensile forces
- Oval holes allow axial compression
- Fixation with Dia. 4.5 mm cortex screws
- Available in both Titanium and Stainless Steel
Profile
- Thickness (T): 1 mm
- Width (W): 11 mm
- Hole Spacing (HS): 16 mm
- Centre Hole Spacing (CHS): 25 mm
|
No. of Holes
|
CODE
|
|
S.S.
|
Titanium
|
|
2 |
640.02 |
640.02T |
|
3 |
640.03 |
640.03T |
|
4 |
640.04 |
640.04T |
|
5 |
640.05 |
640.05T |
|
6 |
640.06 |
640.06T |
|
7 |
640.07 |
640.07T |
|
8 |
640.08 |
640.08T |
|
9 |
640.09
|
640.09T |
|
10 |
640.10 |
640.10T |
|
11 |
640.11 |
640.11T |
|
12 |
640.12 |
640.12T |
* Fixation with 4.5 & 6.5mm Cortex Screw. A Compression effect can be achieved by eccentric positioning of the screw remote from the fracture line.
