| Screw Size |
2.0 mm |
2.4 mm |
2.7 mm |
3.0 mm |
3.5 mm |
4.5 mm |
6.5 mm |
| Leading Thread
(Shaft Thread) |
2.0 mm |
2.4 mm |
2.7 mm |
3.0 mm |
3.5 mm |
4.5 mm |
6.5 mm |
| Trailing Thread
(Head Thread) |
3.0 mm |
3.3 mm |
4.0 mm |
3.5 mm |
4.0 mm |
5.0 mm |
7.5 mm |
| Shaft Diameter |
1.6 mm |
1.8 mm |
1.9 mm |
2.0 mm |
2.7 mm |
3.0 mm |
4.8 mm |
| Guide Wire
Diameter |
0.9 mm |
0.9 mm |
0.9 mm |
1.2 mm |
1.2 mm |
1.2 mm |
2.8 mm |
| Leading
Thread Size |
Approximate 20 % of total length in short thread and 40 % of total length in Long thread |
Approximate 20 % of total length in short thread and 40 % of total length in Long thread |
Approximate 20 % of total length in short thread and 40 % of total length in Long thread |
Approximate 20 % of total length in short thread and 40 % of total length in Long thread |
Approximate 20 % of total length in short thread and 40 % of total length in Long thread |
Approximate 20 % of total length in short thread and 40 % of total length in Long thread |
Thread Length 16 mm and 32 mm |
| Drive |
T7 Sta r Drive |
T7 Sta r Drive |
T10 Star Drive |
T10 Star Drive |
T10 Star Drive |
T15 Star Drive |
4.0mm Hex |
| Lengths
Available |
6-30 mm |
6-30 mm |
6-40 mm |
10-40 mm (Short Thread), 16-40 mm (Long thread) |
10-40 mm (Short Thread), 16-40 mm (Long thread) |
Short Thread: Total Length 20-110 mm, Long Thread: Total Length 30-110 mm, |
16mm Thread: Total length 30-150 mm, 32 mm thread 45-150 mm |
| Item Code |
A701 |
A702 |
A703 |
A704 |
A705 |
A706 |
A707 |
