Large Fragment Plating System

fixLOCK Condylar Buttress Plate, 4.5 mm

Indications:

Intra-articular and extra-articular fractures of lateral or medial condyle femur
Supracondylar fractures of femoral condyle
Malunions and nonunions of the distal femur

Specifications
Product Video

Anatomically shaped- right or left configured eliminating need for intraoperative plate modification
Thin distal end with low profile construct for minimum implant prominence
Fixed angle construct with multiple screw option in metaphysis gives surgeon a versatile fixation option
Smaller area of post-fixation avascularity
The combination of conventional and locking screws offers optimum fixation regardless of bone density
Screw heads are recessed into the plate holes for minimum screw prominence especially when used over medial aspect
Available in both Titanium & Stainless steel

No. of Holes	Stainless Steel		Titanium
No. of Holes	Code- Left	Code- Right	Code- Left	Code- Right
6	841.06L	841.06R	841.06TL	841.06TR
8	841.08L	841.08R	841.08TL	841.08TR
10	841.10L	841.10R	841.10TL	841.10TR
12	841.12L	841.12R	841.12TL	841.12TR
14	841.14L	841.14R	841.14TL	841.14TR
16	841.16L	841.16R	841.16TL	841.16TR
18	841.18L	841.18R	841.18TL	841.18TR
